EXPAND DAX Function (Visual calculations)
Retrieves a context with added levels of detail compared to the current context. If an expression is provided, returns its value in the new context, allowing for navigation in hierarchies and calculation at a more detailed level.
Syntax
| Parameter | Attributes | Description |
|---|---|---|
| Expression | Optional |
The expression to be evaluated in the new context. |
| Axis | Optional |
An axis reference. |
| Column | Optional Repeatable |
A column in the data grid. |
| N | Optional |
The number of levels to expand. If omitted, the default value is 1. |
Return values
The value of Expression after EXPAND moves the context down one or more levels. Without Expression, EXPAND does not return a value: it changes the context, and you can use it only as a filter argument of CALCULATE.
Notes
The visual calculation functions have an axis parameter that is defined in the VISUAL SHAPE query syntax produced by the visual calculation feature in Power BI.
Remarks
EXPAND can be used only in a visual calculation. In a measure or in a calculated column, EXPAND returns an error.
EXPAND has two forms. With Expression, EXPAND moves the context down the hierarchy and returns the value of Expression in the new context. With Expression, you must also use Axis or at least one Column, otherwise EXPAND returns an error. Without Expression, EXPAND only moves the context. You can use this form only as a filter argument of CALCULATE, for example CALCULATE ( MAX ( [Sales Amount] ), EXPAND ( ROWS ) ).
A lower level usually has more than one cell for each cell of the current level. Therefore, Expression must aggregate the values, for example with SUM, AVERAGE, MIN, MAX, or COUNT. A column reference without an aggregation, such as EXPAND ( [Sales Amount], ROWS ), returns an error.
With Axis, the levels are all the columns of that axis. N is the number of levels to move down, and the default is 1. N must be 1 or more, otherwise EXPAND returns an error. EXPAND rounds a decimal N to the nearest integer. If N is larger than the number of levels below the current cell, EXPAND stops at the lowest level of the axis.
With one or more Column arguments, EXPAND moves down to the first level that includes all the columns. If the current cell already includes the columns, EXPAND does not move. For example, with Year, Quarter, and Month on rows, EXPAND ( MAX ( [Sales Amount] ), [Month] ) returns the largest month value in a total, year, or quarter row, and the value of the current cell in a month row.
On the lowest level, EXPAND does not move and evaluates Expression in the current cell. If the visual does not have the axis (for example, COLUMNS in a visual with only rows), EXPAND does not move.
To move directly to the lowest level of an axis, use EXPANDALL. To move up the hierarchy, use COLLAPSE.
Examples
-- EXPAND moves the visual calculation down the ROWS axis.
-- The query simulates a matrix with Year, Quarter, and Month on rows.
-- Expression must aggregate the values of the lower level.
-- MaxOfChildren: largest value one level down (N = 1 is the default)
-- MaxOfGrandchildren: largest value two levels down
-- MaxMonth: largest value at the Month level (no move on Month)
-- AvgOfChildren: EXPAND without expression, as a CALCULATE modifier
DEFINE
COLUMN '__V'[MaxOfChildren] = EXPAND ( MAX ( [Sales Amount] ), ROWS )
COLUMN '__V'[MaxOfGrandchildren] = EXPAND ( MAX ( [Sales Amount] ), ROWS, 2 )
COLUMN '__V'[MaxMonth] = EXPAND ( MAX ( [Sales Amount] ), [Month] )
COLUMN '__V'[AvgOfChildren] =
CALCULATE ( AVERAGE ( [Sales Amount] ), EXPAND ( ROWS ) )
VAR __Core =
SUMMARIZECOLUMNS (
ROLLUPADDISSUBTOTAL (
'Date'[Calendar Year Number], "IsGrandTotalRowTotal",
'Date'[Calendar Year Quarter Number], "IsYearTotal",
'Date'[Calendar Year Month Number], "IsQuarterTotal"
),
TREATAS ( { 2007, 2008 }, 'Date'[Calendar Year Number] ),
TREATAS ( { 1, 2, 3, 4, 5, 6 }, 'Date'[Month Number] ),
"Sales_Amount", [Sales Amount]
)
VAR __Input =
SELECTCOLUMNS (
__Core,
"Year", 'Date'[Calendar Year Number],
"Quarter", 'Date'[Calendar Year Quarter Number],
"Month", 'Date'[Calendar Year Month Number],
"IsGrandTotalRowTotal", [IsGrandTotalRowTotal],
"IsYearTotal", [IsYearTotal],
"IsQuarterTotal", [IsQuarterTotal],
"Sales Amount", [Sales_Amount]
)
TABLE '__V' = __Input
WITH VISUAL SHAPE
AXIS ROWS
GROUP [Year] TOTAL [IsGrandTotalRowTotal]
GROUP [Quarter] TOTAL [IsYearTotal]
GROUP [Month] TOTAL [IsQuarterTotal]
ORDER BY [Year] ASC, [Quarter] ASC, [Month] ASC
DENSIFY "IsDensifiedRow"
EVALUATE
SELECTCOLUMNS (
'__V',
"Year", [Year],
"Quarter", [Quarter],
"Month", [Month],
"Sales Amount", [Sales Amount],
"MaxOfChildren", [MaxOfChildren],
"MaxOfGrandchildren", [MaxOfGrandchildren],
"MaxMonth", [MaxMonth],
"AvgOfChildren", [AvgOfChildren]
)
ORDER BY [Year], [Quarter], [Month]
| Year | Quarter | Month | Sales Amount | MaxOfChildren | MaxOfGrandchildren | MaxMonth | AvgOfChildren |
|---|---|---|---|---|---|---|---|
| (Blank) | (Blank) | (Blank) | 10,247,701.35 | 5,693,275.41 | 3,046,602.02 | 1,128,104.82 | 5,123,850.68 |
| 2007 | (Blank) | (Blank) | 5,693,275.41 | 3,046,602.02 | 1,128,104.82 | 1,128,104.82 | 2,846,637.70 |
| 2007 | 20071 | (Blank) | 2,646,673.39 | 961,289.24 | 961,289.24 | 961,289.24 | 882,224.46 |
| 2007 | 20071 | 200701 | 794,248.24 | 794,248.24 | 794,248.24 | 794,248.24 | 794,248.24 |
| 2007 | 20071 | 200702 | 891,135.91 | 891,135.91 | 891,135.91 | 891,135.91 | 891,135.91 |
| 2007 | 20071 | 200703 | 961,289.24 | 961,289.24 | 961,289.24 | 961,289.24 | 961,289.24 |
| 2007 | 20072 | (Blank) | 3,046,602.02 | 1,128,104.82 | 1,128,104.82 | 1,128,104.82 | 1,015,534.01 |
| 2007 | 20072 | 200704 | 1,128,104.82 | 1,128,104.82 | 1,128,104.82 | 1,128,104.82 | 1,128,104.82 |
| 2007 | 20072 | 200705 | 936,192.74 | 936,192.74 | 936,192.74 | 936,192.74 | 936,192.74 |
| 2007 | 20072 | 200706 | 982,304.46 | 982,304.46 | 982,304.46 | 982,304.46 | 982,304.46 |
| 2008 | (Blank) | (Blank) | 4,554,425.94 | 2,738,040.73 | 999,667.17 | 999,667.17 | 2,277,212.97 |
| 2008 | 20081 | (Blank) | 1,816,385.21 | 656,766.69 | 656,766.69 | 656,766.69 | 605,461.74 |
| 2008 | 20081 | 200801 | 656,766.69 | 656,766.69 | 656,766.69 | 656,766.69 | 656,766.69 |
| 2008 | 20081 | 200802 | 600,080.00 | 600,080.00 | 600,080.00 | 600,080.00 | 600,080.00 |
| 2008 | 20081 | 200803 | 559,538.52 | 559,538.52 | 559,538.52 | 559,538.52 | 559,538.52 |
| 2008 | 20082 | (Blank) | 2,738,040.73 | 999,667.17 | 999,667.17 | 999,667.17 | 912,680.24 |
| 2008 | 20082 | 200804 | 999,667.17 | 999,667.17 | 999,667.17 | 999,667.17 | 999,667.17 |
| 2008 | 20082 | 200805 | 893,231.96 | 893,231.96 | 893,231.96 | 893,231.96 | 893,231.96 |
| 2008 | 20082 | 200806 | 845,141.60 | 845,141.60 | 845,141.60 | 845,141.60 | 845,141.60 |
